X射线光管 (CAS No.None)
- 物化性质
- X射线光管是一种真空电子器件，利用高压电场加速电子轰击金属靶材产生X射线。阳极靶材通常采用高熔点金属（如钨、钼、铑、银、钯等），出射窗采用铍材料以保证X射线有效透过。
English description（英文原文，共 1063 字符）
Product Name:X-ray Tube
English Name:X-ray Tube
Aliases:X-ray tube, X-ray source
Physical Properties:An X-ray tube is a vacuum electronic device that generates X-rays by accelerating electrons in a high-voltage electric field to bombard a metal target. The anode target is typically made of high-melting-point metals (such as tungsten, molybdenum, rhodium, silver, palladium, etc.), and the exit window is made of beryllium to ensure efficient transmission of X-rays.
Uses:X-ray tubes are core components in X-ray fluorescence spectrometry, X-ray diffraction analysis, non-destructive testing, and medical imaging systems, providing a stable and controllable X-ray source.
Technical Specifications:
Anode current: 0 to 1.0 mA
Anode (target) voltage: 4 to 50 kV
Power: 50 W (continuous)
Filament voltage: 2.0 V, filament current: 1.7 A
Stability: 0.2% within 4 hours
Focal spot size: 110 μm (nominal)
Cathode target materials: tungsten, molybdenum, rhodium, silver, palladium, etc.
Exit window: beryllium window, 125 μm thickness (options: 75, 250 μm)
English Name:X-ray Tube
Aliases:X-ray tube, X-ray source
Physical Properties:An X-ray tube is a vacuum electronic device that generates X-rays by accelerating electrons in a high-voltage electric field to bombard a metal target. The anode target is typically made of high-melting-point metals (such as tungsten, molybdenum, rhodium, silver, palladium, etc.), and the exit window is made of beryllium to ensure efficient transmission of X-rays.
Uses:X-ray tubes are core components in X-ray fluorescence spectrometry, X-ray diffraction analysis, non-destructive testing, and medical imaging systems, providing a stable and controllable X-ray source.
Technical Specifications:
Anode current: 0 to 1.0 mA
Anode (target) voltage: 4 to 50 kV
Power: 50 W (continuous)
Filament voltage: 2.0 V, filament current: 1.7 A
Stability: 0.2% within 4 hours
Focal spot size: 110 μm (nominal)
Cathode target materials: tungsten, molybdenum, rhodium, silver, palladium, etc.
Exit window: beryllium window, 125 μm thickness (options: 75, 250 μm)
