旋转蒸发仪ATR-001 (CAS No.None)
- 物化性质
- 主机采用数字显示，可同时显示设定温度和实际温度。温控范围20-180°C，调节精度±1°C。转速范围35-200rpm，高度可在180mm范围内调节，倾斜角度可调0-30度。冷凝器采用双蝶螺旋结构，冷凝面积1460cm2，配有PTFE材质密封圈，耐受几乎所有常规试剂。水浴锅容积4L，可使用水或导热油作为导热介质。整体尺寸650×420×900mm，设备重量19-20kg。
- 技术参数
- 蒸发容积50-2000mL，最大装样量2000mL 温度范围20-180°C，调节精度±1°C，加热功率1500W 转速范围35-200rpm，高度调整范围180mm，倾斜角度0-30度 冷凝器为双蝶螺旋结构，冷凝面积1460cm2 水浴锅容积4L，使用PTFE材质密封圈
English description（英文原文，共 1500 字符）
Product Name:Rotary Evaporator ATR-001
English Name:Rotary Evaporator ATR-001
Aliases:Rotavap, Rotary Evaporator, Rotovap
Physical Properties:The main unit features a digital display showing both set and actual temperatures. Temperature control range is 20-180°C with a precision of ±1°C. Rotation speed ranges from 35-200rpm, with 180mm vertical height adjustment and 0-30 degree tilting angle adjustment. The condenser adopts a double-butterfly spiral structure with a condensation area of 1460cm2, equipped with a PTFE sealing ring that resists almost all conventional reagents. The heating bath has a 4L capacity and accepts water or thermal oil as the heating medium. Overall dimensions are 650×420×900mm, with a unit weight of 19-20kg.
Uses:Used for concentration, crystallization, drying, separation and solvent recovery in pharmaceutical, chemical and biopharmaceutical industries. It is particularly suitable for evaporation and concentration of heat-sensitive substances under reduced pressure, playing an important role in experiments and production scenarios requiring large sample volumes and high-efficiency solvent recovery.
Technical Specifications:
Evaporation capacity 50-2000mL, maximum sample loading 2000mL
Temperature range 20-180°C, control precision ±1°C, heating power 1500W
Rotation speed range 35-200rpm, height adjustment 180mm, tilting angle 0-30 degrees
Double-butterfly spiral condenser with condensation area of 1460cm2
4L heating bath with PTFE sealing ring
English Name:Rotary Evaporator ATR-001
Aliases:Rotavap, Rotary Evaporator, Rotovap
Physical Properties:The main unit features a digital display showing both set and actual temperatures. Temperature control range is 20-180°C with a precision of ±1°C. Rotation speed ranges from 35-200rpm, with 180mm vertical height adjustment and 0-30 degree tilting angle adjustment. The condenser adopts a double-butterfly spiral structure with a condensation area of 1460cm2, equipped with a PTFE sealing ring that resists almost all conventional reagents. The heating bath has a 4L capacity and accepts water or thermal oil as the heating medium. Overall dimensions are 650×420×900mm, with a unit weight of 19-20kg.
Uses:Used for concentration, crystallization, drying, separation and solvent recovery in pharmaceutical, chemical and biopharmaceutical industries. It is particularly suitable for evaporation and concentration of heat-sensitive substances under reduced pressure, playing an important role in experiments and production scenarios requiring large sample volumes and high-efficiency solvent recovery.
Technical Specifications:
Evaporation capacity 50-2000mL, maximum sample loading 2000mL
Temperature range 20-180°C, control precision ±1°C, heating power 1500W
Rotation speed range 35-200rpm, height adjustment 180mm, tilting angle 0-30 degrees
Double-butterfly spiral condenser with condensation area of 1460cm2
4L heating bath with PTFE sealing ring
