旋转蒸发仪 TL-RE2000/3000/5000系列(水浴) (CAS No.None)

Product Name:Rotary Evaporator TL-RE2000/3000/5000 Series (Water Bath)

English Name:Rotary Evaporator TL-RE2000/3000/5000 Series (Water Bath)

Aliases:Rotary vacuum evaporator, Rotavapor, Water bath rotary evaporator

Physical Properties:The TL-RE2000/3000/5000 series water-bath rotary evaporators have evaporating flask capacities of 0.25-2 L, 0.25-3 L and 0.25-5 L respectively. They feature digital electronic stepless speed regulation (0-310 rpm), timed forward/reverse rotation, automatic lift (0-150 mm), and digital display of bath temperature from room temperature to 99°C. Heating power is 1.5 kW for RE2000/RE3000 and 1.8 kW for RE5000. The units are equipped with a mechanical vacuum gauge and are available with ball-joint or standard-taper condensers.

Uses:Used for vacuum distillation, solvent recovery, concentration, crystallization and drying. Suitable for laboratories and small-scale production in chemical, pharmaceutical and biochemical fields, especially for gentle evaporation of heat-sensitive materials.

Technical Specifications:

Series models: TL-RE2000A/B, TL-RE3000A/B, TL-RE5000A/B; type A is equipped with a ball-joint condenser, type B with a standard-taper condenser.

Evaporating flask capacity: RE2000 0.25-2 L, RE3000 0.25-3 L, RE5000 0.25-5 L.

Speed: digital electronic stepless adjustment, 0-310 rpm, with timed forward/reverse rotation; motor power 40 W.

Lifting: automatic lift, travel 0-150 mm; digital display of water bath temperature, room temperature to 99°C.

Heating power: RE2000/RE3000 1.5 kW, RE5000 1.8 kW; equipped with mechanical vacuum gauge.
