XWH-225型VOC释放量环境测试舱 (CAS No.None)

Product Name:XWH-225 VOC Emission Environmental Test Chamber

English Name:XWH-225 VOC Emission Environmental Test Chamber

Aliases:VOC Emission Environmental Test Chamber, Formaldehyde Emission Environmental Chamber, Environmental Test Chamber

Physical Properties:The chamber features a horizontal stainless steel structure, equipped with a precision temperature and humidity control system, air exchange system, and clean air supply system. With a chamber volume of 225L, the temperature control range is 15–40℃, humidity control range is 30–80%RH, air exchange rate is 0.2–2 times/hour, and air velocity is continuously adjustable from 0.1 to 0.3m/s. The background concentration is extremely low, with formaldehyde <0.006mg/m³, TVOC <0.05mg/m³, and individual VOC <0.005mg/m³. The leakage rate is less than 3% of the airflow at a relative pressure of 1kPa, demonstrating excellent sealing performance. Power supply: 220V, 16A, 50Hz; rated power 3kW, operating power 1.5kW.

Uses:Mainly used for detecting VOC and formaldehyde emission from wood-based panels, carpets, toys, textiles, and other light industrial products. It simulates indoor environmental conditions and provides a standardized testing platform for evaluating product environmental performance, serving as important equipment for limit detection of harmful substances in interior decoration materials.

Technical Specifications:

Chamber volume: 225L (0.225m³); overall dimensions: W960×D1500×H1460mm

Temperature range: 15–40℃, temperature deviation ±0.5℃

Humidity range: 30–80%RH, regulation accuracy ±3%RH

Air exchange rate: 0.2–2 times/hour, accuracy 0.05 times/hour; air velocity: 0.1–0.3m/s continuously adjustable

Compliant standards: ASTM D6007-02, ASTM D5116-97, ASTM D6330-98, EN 13419-1, EN 717-1
