YC-018实验室大颗粒喷雾干燥机 (CAS No.None)
- 中文别名
- 实验室喷雾干燥机；大颗粒喷雾干燥机
- 英文名称
- YC-018 Laboratory Large Particle Spray Dryer
- 所属类别
- 试剂实验设备
- 物化性质
- 整机采用优质不锈钢材料精密制造，喷雾、烘干及收集系统均为不锈钢结构；采用二流体喷雾雾化结构，配备塔壁吹扫装置；彩色触摸屏操作，支持全自动与手动控制，组件易拆卸、易清洗。
- 技术参数
- 进风温度控制范围30℃~280℃，出风温度控制范围30℃~140℃，加热控温精度±1℃。 蒸发水量1500~2000 mL/h，最小进料量50 mL，最大进料量2000 mL/h（蠕动泵可调）。 喷嘴口径可选0.5/0.7/1.0/1.5/2.0 mm，并可定制；配备通针式喷咀清洁器，堵塞时自动清除。 干燥时间1.0~1.5 s，干燥后颗粒粒径最大可达100 μm，粒度呈正态分布，流动性好。 整机采用优质不锈钢材质，配置全无油空压机，配备彩色LCD触摸屏（显示进/出风口温度、蠕动泵转速、风量、通针频率），全自动/手动双模式，具有关机保护功能，噪音小于60 dB。
English description（英文原文，共 1925 字符）
Product Name:YC-018 Laboratory Large Particle Spray Dryer
English Name:YC-018 Laboratory Large Particle Spray Dryer
Aliases:Laboratory spray dryer, Large particle spray dryer
Physical Properties:The whole machine is precision-manufactured from high-quality stainless steel, with the spray, drying and collection systems all made of stainless steel. It adopts a two-fluid spray atomization structure and is equipped with a tower wall purging device. It features a color touch screen, supports both fully automatic and manual control, and all components are easy to disassemble and clean.
Uses:Mainly used in laboratories of universities, research institutes and food, pharmaceutical and chemical enterprises to produce trace particles of 10–100 microns. It is applicable to various solutions such as emulsions and suspensions, as well as heat-sensitive materials like biological products, biopesticides and enzyme preparations. As the material is only heated momentarily when sprayed into fine mist particles, the active ingredients remain undamaged after drying.
Technical Specifications:
Inlet air temperature control range 30–280°C, outlet air temperature control range 30–140°C, heating control accuracy ±1°C.
Evaporation capacity 1500–2000 mL/h, minimum feed volume 50 mL, maximum feed volume 2000 mL/h (adjustable by peristaltic pump).
Nozzle diameters 0.5/0.7/1.0/1.5/2.0 mm are optional and customizable; equipped with a needle-type atomizer cleaner that automatically clears blockages.
Drying time 1.0–1.5 s, particle size after drying up to 100 μm with normal size distribution and good fluidity.
The whole machine is made of high-quality stainless steel, equipped with an oil-free air compressor and a color LCD touch screen (displaying inlet/outlet temperature, peristaltic pump speed, air flow and needle frequency), full-automatic/manual dual modes, shutdown protection function, and noise below 60 dB.
English Name:YC-018 Laboratory Large Particle Spray Dryer
Aliases:Laboratory spray dryer, Large particle spray dryer
Physical Properties:The whole machine is precision-manufactured from high-quality stainless steel, with the spray, drying and collection systems all made of stainless steel. It adopts a two-fluid spray atomization structure and is equipped with a tower wall purging device. It features a color touch screen, supports both fully automatic and manual control, and all components are easy to disassemble and clean.
Uses:Mainly used in laboratories of universities, research institutes and food, pharmaceutical and chemical enterprises to produce trace particles of 10–100 microns. It is applicable to various solutions such as emulsions and suspensions, as well as heat-sensitive materials like biological products, biopesticides and enzyme preparations. As the material is only heated momentarily when sprayed into fine mist particles, the active ingredients remain undamaged after drying.
Technical Specifications:
Inlet air temperature control range 30–280°C, outlet air temperature control range 30–140°C, heating control accuracy ±1°C.
Evaporation capacity 1500–2000 mL/h, minimum feed volume 50 mL, maximum feed volume 2000 mL/h (adjustable by peristaltic pump).
Nozzle diameters 0.5/0.7/1.0/1.5/2.0 mm are optional and customizable; equipped with a needle-type atomizer cleaner that automatically clears blockages.
Drying time 1.0–1.5 s, particle size after drying up to 100 μm with normal size distribution and good fluidity.
The whole machine is made of high-quality stainless steel, equipped with an oil-free air compressor and a color LCD touch screen (displaying inlet/outlet temperature, peristaltic pump speed, air flow and needle frequency), full-automatic/manual dual modes, shutdown protection function, and noise below 60 dB.
