有机溶剂实验型喷雾干燥机 (CAS No.None)
- 中文别名
- 实验室喷雾干燥机；小型喷雾干燥机；实验型喷雾干燥机
- 英文名称
- Organic Solvent Laboratory Spray Dryer
- 所属类别
- 试剂实验设备
- 技术参数
- 全自动与手动双重控制模式，彩色触摸屏动态显示，配备485通讯接口可远程控制 进风温度控制范围30℃~400℃，出风温度控制范围30℃~200℃，PID实时控温精度±1℃ 蒸发水量1500mL/h~2000mL/h，蠕动泵最大进料量2000mL/h，最小进料量30mL 干燥时间0.8~1.0秒，喷嘴口径0.5mm/0.7mm/0.75mm/1.0mm/1.5mm/2.0mm可选，配备自动通针防堵塞装置 整机功率3.8KW/220V，设备尺寸1380mm(高)×770mm(长)×590mm(宽)，与物料接触部分采用不锈钢及高硼硅耐热玻璃制造，塔体配有冷风夹套和气扫装置
English description（英文原文，共 1898 字符）
Product Name:Organic Solvent Laboratory Spray Dryer
English Name:Organic Solvent Laboratory Spray Dryer
Aliases:Laboratory Spray Dryer, Mini Spray Dryer, Experimental Spray Dryer
Uses:Mainly used for R&D and production of trace granular powders in universities, research institutes, and enterprise laboratories in food, biological, beverage, chemical, material, pharmaceutical and other industries. It has broad applicability to various solutions such as emulsions and suspensions, and is suitable for drying heat-sensitive materials such as biological products, biological pesticides, and enzyme preparations, as well as spray drying of organic solvent systems. Since the sprayed material is only exposed to high temperature instantaneously in the form of fine mist particles, the active ingredients can remain intact after drying. Widely applied in beverages, flavors and pigments, milk and egg products, plant and vegetable extracts, pharmaceutical synthesis, heat-sensitive plastics, polymers and resins, biochemical products, dyes, ceramics, detergents and other fields.
Technical Specifications:
Dual control modes of fully automatic and manual operation, dynamic display on color touch screen, equipped with 485 communication interface for remote control
Inlet air temperature control range 30°C~400°C, outlet air temperature control range 30°C~200°C, PID real-time temperature control accuracy ±1°C
Evaporation capacity 1500mL/h~2000mL/h, maximum feed rate 2000mL/h by peristaltic pump, minimum feed rate 30mL
Drying time 0.8~1.0s; nozzle orifices 0.5mm/0.7mm/0.75mm/1.0mm/1.5mm/2.0mm optional; equipped with automatic needle cleaning device to prevent blockage
Total power 3.8KW/220V; dimensions 1380mm(H)×770mm(L)×590mm(W); parts in contact with material made of stainless steel and high borosilicate heat-resistant glass; tower equipped with cold air jacket and air sweep device
English Name:Organic Solvent Laboratory Spray Dryer
Aliases:Laboratory Spray Dryer, Mini Spray Dryer, Experimental Spray Dryer
Uses:Mainly used for R&D and production of trace granular powders in universities, research institutes, and enterprise laboratories in food, biological, beverage, chemical, material, pharmaceutical and other industries. It has broad applicability to various solutions such as emulsions and suspensions, and is suitable for drying heat-sensitive materials such as biological products, biological pesticides, and enzyme preparations, as well as spray drying of organic solvent systems. Since the sprayed material is only exposed to high temperature instantaneously in the form of fine mist particles, the active ingredients can remain intact after drying. Widely applied in beverages, flavors and pigments, milk and egg products, plant and vegetable extracts, pharmaceutical synthesis, heat-sensitive plastics, polymers and resins, biochemical products, dyes, ceramics, detergents and other fields.
Technical Specifications:
Dual control modes of fully automatic and manual operation, dynamic display on color touch screen, equipped with 485 communication interface for remote control
Inlet air temperature control range 30°C~400°C, outlet air temperature control range 30°C~200°C, PID real-time temperature control accuracy ±1°C
Evaporation capacity 1500mL/h~2000mL/h, maximum feed rate 2000mL/h by peristaltic pump, minimum feed rate 30mL
Drying time 0.8~1.0s; nozzle orifices 0.5mm/0.7mm/0.75mm/1.0mm/1.5mm/2.0mm optional; equipped with automatic needle cleaning device to prevent blockage
Total power 3.8KW/220V; dimensions 1380mm(H)×770mm(L)×590mm(W); parts in contact with material made of stainless steel and high borosilicate heat-resistant glass; tower equipped with cold air jacket and air sweep device
