圆形电动升降水浴氮吹仪试管架 (CAS No.None)

Product Name:Round Electric Lifting Water Bath Nitrogen Blowdown Concentrator Test Tube Rack

English Name:Round Electric Lifting Water Bath Nitrogen Blowdown Concentrator Test Tube Rack

Aliases:Round Water Bath Nitrogen Blowdown Concentrator Test Tube Rack, Electric Lifting Nitrogen Blowdown Concentrator Sample Rack

Physical Properties:Round structure that rotates freely, facilitating sample rack entry and exit in the water bath. The sample plate adopts electric lifting with a lift height of 0-150 mm and 360° rotation space. Made of high-quality stainless steel, resistant to acids, alkalis and other organic solvents. Equipped with an intelligent digital temperature controller with PID adjustment, over-temperature alarm and anti-dry burning protection.

Uses:Widely used in pesticide residue analysis (vegetables, fruits, grains, etc.), pharmaceutical testing, environmental analysis, biological analysis, commodity inspection and food & beverage testing. Nitrogen or other inert gases are blown onto the sample surface to achieve rapid oxygen-free concentration of sample solutions. Suitable for food safety, medicine, pesticide residue detection and clinical pharmacokinetics applications.

Technical Specifications:

Sample capacity: 12 positions with spring test tube clamps for positioning, each sample has a digital number; a 24-position model is also available.

Test tube range: 10~55 mm (12-position model) or 10~29 mm (24-position model).

Temperature control range: room temperature to 100℃, accuracy ±1℃, 4-digit display/PID adjustment/over-temperature alarm.

Timing range: 0~99h59min; gas flow rate controllable 0-15 L/min; nitrogen consumption 330 mL/min/sample.

Power: 1000 W; weight: 10 kg (12-position) / 12 kg (24-position).
