圆形防水推拉自锁连接器 FX系列金属航空插头 (CAS No.None)
- 中文别名
- FX系列连接器；金属航空插头；推拉自锁连接器
- 英文名称
- FX Series Circular Waterproof Push-Pull Self-Locking Connector (Metal Aviation Plug)
- 所属类别
- 试剂实验设备
- 物化性质
- 采用直式推拉锁紧结构，插头插座可实现快速连接与分离；壳体号FX101外径仅12.4mm；具备屏蔽、密封、耐环境、长寿命等特点；多键定位设计，具有防误插功能；插座为螺母紧固安装形式，配有导电O型圈，具备屏蔽密封性能；插头、插座均既可装插针又可装插孔；高速和低频电接触件端接形式为导线焊接式及直式印制板焊接式。
English description（英文原文，共 2064 字符）
Product Name:FX Series Circular Waterproof Push-Pull Self-Locking Connector (Metal Aviation Plug)
English Name:FX Series Circular Waterproof Push-Pull Self-Locking Connector (Metal Aviation Plug)
Aliases:FX Series Connector, Metal Aviation Plug, Push-Pull Self-Locking Connector
Physical Properties:Adopts straight push-pull locking structure, allowing rapid connection and separation between plug and socket; shell size FX101 has an outer diameter of only 12.4mm; features shielding, sealing, environmental resistance and long service life; multi-key positioning design prevents mis-mating; socket is mounted with nut fastening and equipped with conductive O-ring for shielding and sealing; both plug and socket can be fitted with either pins or sockets; high-speed and low-frequency contacts are terminated by wire soldering or straight PCB soldering.
Uses:Suitable for signal connection and transmission of AC/DC, high-speed, RF, and fiber optic in military and civil applications such as radio equipment, infantry equipment, rugged computers, test and measurement equipment, audio/video equipment, data acquisition, and industrial control. It supports direct transmission of various standard high-speed protocols (USB2.0, USB3.0, HDMI, SATA, DP, Gigabit Ethernet, 10G Ethernet, etc.) and enables integrated transmission of low-frequency, power, high-speed, RF and fiber optic signals in a single connector.
Technical Specifications:
Mechanical life: 5000 cycles.
Vibration: for shell sizes 101/102, sinusoidal vibration 10-2000Hz, acceleration 147m/s², discontinuity ≤1μs; for shell sizes 103/1031/104/105/106, random vibration PSD 1.0g²/Hz, RMS 36.6g, discontinuity ≤1μs.
Shock: acceleration 2940m/s², discontinuity ≤1μs.
Operating temperature: -55°C to +125°C; relative humidity: up to 95% at 40°C.
Socket leakage rate: ≤1.0 Pa·cm³/s under pressure difference of 1×10⁵Pa (except fiber optic/RF products); mated plug-socket withstands water pressure of 2m depth for 24h (except fiber optic/RF products); salt spray: aluminum alloy/copper alloy ≥96h.
English Name:FX Series Circular Waterproof Push-Pull Self-Locking Connector (Metal Aviation Plug)
Aliases:FX Series Connector, Metal Aviation Plug, Push-Pull Self-Locking Connector
Physical Properties:Adopts straight push-pull locking structure, allowing rapid connection and separation between plug and socket; shell size FX101 has an outer diameter of only 12.4mm; features shielding, sealing, environmental resistance and long service life; multi-key positioning design prevents mis-mating; socket is mounted with nut fastening and equipped with conductive O-ring for shielding and sealing; both plug and socket can be fitted with either pins or sockets; high-speed and low-frequency contacts are terminated by wire soldering or straight PCB soldering.
Uses:Suitable for signal connection and transmission of AC/DC, high-speed, RF, and fiber optic in military and civil applications such as radio equipment, infantry equipment, rugged computers, test and measurement equipment, audio/video equipment, data acquisition, and industrial control. It supports direct transmission of various standard high-speed protocols (USB2.0, USB3.0, HDMI, SATA, DP, Gigabit Ethernet, 10G Ethernet, etc.) and enables integrated transmission of low-frequency, power, high-speed, RF and fiber optic signals in a single connector.
Technical Specifications:
Mechanical life: 5000 cycles.
Vibration: for shell sizes 101/102, sinusoidal vibration 10-2000Hz, acceleration 147m/s², discontinuity ≤1μs; for shell sizes 103/1031/104/105/106, random vibration PSD 1.0g²/Hz, RMS 36.6g, discontinuity ≤1μs.
Shock: acceleration 2940m/s², discontinuity ≤1μs.
Operating temperature: -55°C to +125°C; relative humidity: up to 95% at 40°C.
Socket leakage rate: ≤1.0 Pa·cm³/s under pressure difference of 1×10⁵Pa (except fiber optic/RF products); mated plug-socket withstands water pressure of 2m depth for 24h (except fiber optic/RF products); salt spray: aluminum alloy/copper alloy ≥96h.
