真空干燥箱BV-20 (CAS No.None)
- 物化性质
- 容积24L；温度控制范围：室温+10~200°C；温度控制精度：±1°C；温度分辨率：0.1°C；极限真空度：133Pa；内胆材质：304不锈钢（喷砂处理）；内部尺寸(mm)：300×275×300；外部尺寸(mm)：445×590×505（不含铰链、把手、仪表、电线等突出部分）；净重：60KG；电压：AC220V/50Hz；额定功率：700W；标准隔板数量：2块（最多3块），隔板承重：20KG；具有惰性气体进气口。
- 技术参数
- 采用4.3英寸智能触摸屏控制系统，参数实时显示，可预设7段63步程序（每段9步，每段设置时间1-99小时59分）。 捆绑式搁板加热技术，搁板与内胆精密结合，导热效率比传统方式提高40%，箱内温度均一性提高50%。 真空排气管采用智能电磁阀控制，与真空泵联动，电磁阀开启/关闭时真空泵自动启停，操作安全可靠。 内胆采用304不锈钢喷砂处理，搁板为铝制喷砂材料，耐热耐腐蚀，便于清洁；搁板高度可调。 标配大视角可视窗（钢化防弹双层玻璃）与进口真空表；支持中英文菜单及°C/°F单位切换。
English description（英文原文，共 1996 字符）
Product Name:Vacuum Drying Oven
English Name:Vacuum Drying Oven
Aliases:BV-20, Vacuum Oven, Vacuum Dryer
Physical Properties:Volume: 24L; temperature control range: ambient +10~200°C; temperature control accuracy: ±1°C; temperature resolution: 0.1°C; ultimate vacuum: 133Pa; inner chamber material: 304 stainless steel (sandblasted); internal dimensions (mm): 300×275×300; external dimensions (mm): 445×590×505 (excluding protruding parts such as hinges, handles, instruments and cables); net weight: 60KG; power supply: AC220V/50Hz; rated power: 700W; standard shelf quantity: 2 (up to 3), shelf load capacity: 20KG; equipped with inert gas inlet.
Uses:It is used for vacuum drying of materials in pharmaceutical, food, chemical, electronic and other industries, especially suitable for drying and heat treatment of heat-sensitive, easily decomposable and easily oxidizable materials under vacuum and low-temperature conditions.
Technical Specifications:
Equipped with a 4.3-inch intelligent touch screen control system with real-time parameter display, capable of presetting 7 segments/63 steps of program (9 steps per segment, each step setable from 1 hour to 99 hours 59 minutes).
Bundled shelf heating technology ensures close contact between the shelf and the inner chamber, increasing thermal conductivity by 40% and improving temperature uniformity by 50% compared with traditional methods.
The vacuum exhaust pipe is controlled by an intelligent solenoid valve linked with the vacuum pump; the pump starts/stops automatically when the valve is opened/closed, providing safe and reliable operation.
The inner chamber is made of sandblasted 304 stainless steel and the shelves are made of sandblasted aluminum, offering excellent heat and corrosion resistance and easy cleaning; shelf height is adjustable.
Standard large-viewing-angle observation window (tempered bulletproof double-layer glass) and imported vacuum gauge; supports Chinese/English menu and °C/°F unit switching.
English Name:Vacuum Drying Oven
Aliases:BV-20, Vacuum Oven, Vacuum Dryer
Physical Properties:Volume: 24L; temperature control range: ambient +10~200°C; temperature control accuracy: ±1°C; temperature resolution: 0.1°C; ultimate vacuum: 133Pa; inner chamber material: 304 stainless steel (sandblasted); internal dimensions (mm): 300×275×300; external dimensions (mm): 445×590×505 (excluding protruding parts such as hinges, handles, instruments and cables); net weight: 60KG; power supply: AC220V/50Hz; rated power: 700W; standard shelf quantity: 2 (up to 3), shelf load capacity: 20KG; equipped with inert gas inlet.
Uses:It is used for vacuum drying of materials in pharmaceutical, food, chemical, electronic and other industries, especially suitable for drying and heat treatment of heat-sensitive, easily decomposable and easily oxidizable materials under vacuum and low-temperature conditions.
Technical Specifications:
Equipped with a 4.3-inch intelligent touch screen control system with real-time parameter display, capable of presetting 7 segments/63 steps of program (9 steps per segment, each step setable from 1 hour to 99 hours 59 minutes).
Bundled shelf heating technology ensures close contact between the shelf and the inner chamber, increasing thermal conductivity by 40% and improving temperature uniformity by 50% compared with traditional methods.
The vacuum exhaust pipe is controlled by an intelligent solenoid valve linked with the vacuum pump; the pump starts/stops automatically when the valve is opened/closed, providing safe and reliable operation.
The inner chamber is made of sandblasted 304 stainless steel and the shelves are made of sandblasted aluminum, offering excellent heat and corrosion resistance and easy cleaning; shelf height is adjustable.
Standard large-viewing-angle observation window (tempered bulletproof double-layer glass) and imported vacuum gauge; supports Chinese/English menu and °C/°F unit switching.
