中型真空高低温探针台 (CAS No.None)
- 物化性质
- 设备采用304不锈钢真空腔体，腔体为铰链侧开结构，内腔尺寸φ160×90mm。加热台为φ60mm不锈钢台面，温度范围-196~350℃，温控误差±1℃。观察窗直径70mm，工作距离90mm。真空腔体设有KF25抽气口和3-6mm卡套进气口，支持机械泵或分子泵抽真空。电学性能为绝缘电阻≥4000MΩ，介质耐压≤500V。
English description（英文原文，共 1547 字符）
Product Name:Medium Vacuum High-Low Temperature Probe Station
English Name:Medium Vacuum High-Low Temperature Probe Station
Aliases:Vacuum Probe Station, High-Low Temperature Probe Station, Vacuum Cryogenic Probe Station
Physical Properties:The equipment features a 304 stainless steel vacuum chamber with a side-hinged lid, internal chamber dimensions of φ160×90mm. The heating stage is a φ60mm stainless steel platform with a temperature range of -196~350℃ and temperature control accuracy of ±1℃. The observation window is φ70mm with a working distance of 90mm. The chamber is equipped with a KF25 vacuum port and a 3-6mm ferrule gas inlet, compatible with mechanical or molecular pumps. Electrical performance: insulation resistance ≥4000MΩ, dielectric withstand voltage ≤500V.
Uses:Used for testing semiconductor, optoelectronic, integrated circuit, and packaging devices. Suitable for R&D of precise electrical measurements on complex, high-speed devices, ensuring quality and reliability while reducing development time and device manufacturing costs.
Technical Specifications:
Heating stage temperature range: -196~350℃, temperature control accuracy ±1℃
Vacuum degree: mechanical pump ≤10Pa, molecular pump ≤10⁻³Pa, maximum positive pressure ≤0.1MPa
Probes: 4 tungsten probes with 10μm tip, electrical signal connectors SMA to BNC×4
Probe positioning stage: X-axis travel 30mm±15mm, Y/Z-axis travel 13mm±12.5mm, control accuracy ≤0.01mm
Microscopy: magnification 19-135x, field of view 15×13-2.25×1.7mm, minimum resolution 0.08mm
English Name:Medium Vacuum High-Low Temperature Probe Station
Aliases:Vacuum Probe Station, High-Low Temperature Probe Station, Vacuum Cryogenic Probe Station
Physical Properties:The equipment features a 304 stainless steel vacuum chamber with a side-hinged lid, internal chamber dimensions of φ160×90mm. The heating stage is a φ60mm stainless steel platform with a temperature range of -196~350℃ and temperature control accuracy of ±1℃. The observation window is φ70mm with a working distance of 90mm. The chamber is equipped with a KF25 vacuum port and a 3-6mm ferrule gas inlet, compatible with mechanical or molecular pumps. Electrical performance: insulation resistance ≥4000MΩ, dielectric withstand voltage ≤500V.
Uses:Used for testing semiconductor, optoelectronic, integrated circuit, and packaging devices. Suitable for R&D of precise electrical measurements on complex, high-speed devices, ensuring quality and reliability while reducing development time and device manufacturing costs.
Technical Specifications:
Heating stage temperature range: -196~350℃, temperature control accuracy ±1℃
Vacuum degree: mechanical pump ≤10Pa, molecular pump ≤10⁻³Pa, maximum positive pressure ≤0.1MPa
Probes: 4 tungsten probes with 10μm tip, electrical signal connectors SMA to BNC×4
Probe positioning stage: X-axis travel 30mm±15mm, Y/Z-axis travel 13mm±12.5mm, control accuracy ≤0.01mm
Microscopy: magnification 19-135x, field of view 15×13-2.25×1.7mm, minimum resolution 0.08mm
