ALCOM PA66 910/1 GF15 PTFE10 (CAS No.None)

Product Name:ALCOM PA66 910/1 GF15 PTFE10

English Name:ALCOM PA66 910/1 GF15 PTFE10

CAS No.:32131-17-2

Aliases:Nylon 66, Poly(hexamethylene adipamide), PA66 + 15% glass fiber + 10% PTFE

Molecular Formula:(C12H22N2O2)n

Physical Properties:A modified compound based on PA66 (Nylon 66) reinforced with 15% glass fiber and lubricated with 10% PTFE (polytetrafluoroethylene). PA66 is a translucent or opaque milky white crystalline polymer with amide groups in the main chain, a number-average molecular weight of about 15,000-30,000, a density of about 1.14 g/cm³ and a melting point of 255-265°C. The addition of glass fiber significantly improves rigidity, strength and heat resistance; the addition of PTFE provides a low friction coefficient and excellent self-lubricating properties. This grade has a density of about 1.35 g/cm³, low water absorption and good dimensional stability.

Uses:Suitable for manufacturing wear-resistant, self-lubricating precision mechanical parts such as gears, bearings, sliders, bushings and seals. Widely used in heat-resistant and wear-resistant structural parts in the automotive industry, electronic and electrical components, and sliding parts of textile machinery.

Technical Specifications:

Density: approx. 1.35 g/cm³

Tensile strength: ≥90 MPa

Flexural modulus: ≥4500 MPa

Heat deflection temperature (1.8 MPa): ≥220°C

Friction coefficient: 0.2-0.3 (self-lubricating)
