本色PEEK管/本色PEEK棒/PEEK板 (CAS No.None)

Product Name:Natural PEEK Tube / Natural PEEK Rod / PEEK Sheet

English Name:Natural PEEK Tube / Natural PEEK Rod / PEEK Sheet

CAS No.:29658-26-2

Aliases:Polyether ether ketone tube, Polyether ether ketone rod, Polyether ether ketone sheet

Molecular Formula:(C19H14O3)n

Physical Properties:PEEK is a semi-crystalline aromatic thermoplastic polymer with a density of approximately 1.30 g/cm³, a melting point of about 343°C, a glass transition temperature of approximately 143°C, and a long-term continuous service temperature up to 260°C. It exhibits excellent chemical resistance, radiation resistance, flame retardancy (UL94 V-0), and mechanical strength, along with a low friction coefficient, outstanding wear resistance, and good electrical insulation properties.

Uses:PEEK is widely used in aerospace, pharmaceutical, and food processing industries, including gas analyzer structural components and heat exchanger wiper blades. Due to its excellent friction properties, it is an ideal material for manufacturing friction components such as sleeve bearings, plain bearings, valve seats, seal rings, and pump wear rings.

Technical Specifications:

Plate: thickness 5–100 mm, width 500/620/1000 mm, length 1000 mm

Rod: diameter 3–200 mm, length 1000 mm

Appearance: earth gray, black

Main grades: PEEK-1000 (pure resin, brown-gray), PEEK-HPV (bearing grade, black), PEEK-GF30 (30% glass fiber reinforced, brown-gray), PEEK-CA30 (30% carbon fiber reinforced, black)

Origin: Germany, Switzerland, USA, Japan
