单层玻璃反应釜 (CAS No.None)
- 物化性质
- 釜体采用GG-17高硼硅玻璃材质，具备优良的耐高温和耐腐蚀性能。反应釜可在-80~250℃温度范围内运行，真空度可达0.098Mpa。配备万向地角轮，移动方便，反应瓶口为球形七口设计，便于连接多种实验装置。
- 技术参数
- 型号分为F-10L、F-20L、F-30L，反应瓶容积分别为10L、20L、30L 釜体反应温度范围为-80~250℃，真空度可达0.098Mpa 搅拌转速为0-450rpm，搅拌轴径15mm，搅拌功率分别为90W 1/3、90W 1/3、120W 1/3 加热功率分别为3KW、5KW、8KW，放料口离地高度450mm 玻璃材质为GG-17高硼硅玻璃，反应瓶口为球形七口设计
English description（英文原文，共 1401 字符）
Product Name:Single-layer Glass Reactor
English Name:Single-layer Glass Reactor
Aliases:Single-layer Glass Reaction Vessel, Glass Reaction Kettle
Physical Properties:The reactor body is made of GG-17 borosilicate glass, offering excellent high-temperature resistance and corrosion resistance. It operates within a temperature range of -80 to 250°C and can achieve a vacuum degree of 0.098 MPa. Equipped with universal casters for easy mobility, the reactor features a spherical seven-port design to facilitate connection with various experimental setups.
Uses:Used for chemical synthesis, distillation, reflux, extraction, and other reaction processes. Suitable for pharmaceuticals, fine chemicals, bioengineering, and scientific research. Supports stirring reactions under atmospheric or reduced pressure to meet diverse material processing requirements.
Technical Specifications:
Models include F-10L, F-20L, and F-30L, with reaction vessel capacities of 10L, 20L, and 30L respectively
Operating temperature range of -80 to 250°C, with a vacuum degree up to 0.098 MPa
Stirring speed of 0-450 rpm, stirring shaft diameter of 15mm, and stirring power of 90W 1/3, 90W 1/3, and 120W 1/3 respectively
Heating power of 3KW, 5KW, and 8KW respectively, with a discharge port height of 450mm above ground
Constructed of GG-17 borosilicate glass, designed with a spherical seven-port reactor opening
English Name:Single-layer Glass Reactor
Aliases:Single-layer Glass Reaction Vessel, Glass Reaction Kettle
Physical Properties:The reactor body is made of GG-17 borosilicate glass, offering excellent high-temperature resistance and corrosion resistance. It operates within a temperature range of -80 to 250°C and can achieve a vacuum degree of 0.098 MPa. Equipped with universal casters for easy mobility, the reactor features a spherical seven-port design to facilitate connection with various experimental setups.
Uses:Used for chemical synthesis, distillation, reflux, extraction, and other reaction processes. Suitable for pharmaceuticals, fine chemicals, bioengineering, and scientific research. Supports stirring reactions under atmospheric or reduced pressure to meet diverse material processing requirements.
Technical Specifications:
Models include F-10L, F-20L, and F-30L, with reaction vessel capacities of 10L, 20L, and 30L respectively
Operating temperature range of -80 to 250°C, with a vacuum degree up to 0.098 MPa
Stirring speed of 0-450 rpm, stirring shaft diameter of 15mm, and stirring power of 90W 1/3, 90W 1/3, and 120W 1/3 respectively
Heating power of 3KW, 5KW, and 8KW respectively, with a discharge port height of 450mm above ground
Constructed of GG-17 borosilicate glass, designed with a spherical seven-port reactor opening
共 1 家生产厂家、批发商，
1 条供应报价
供应报价
常见问题
- 单层玻璃反应釜的 CAS 号是多少？
- 单层玻璃反应釜的 CAS 号是 None。
- 单层玻璃反应釜的英文名称是什么？
- 单层玻璃反应釜的英文名称为 Single-layer Glass Reactor。
- 单层玻璃反应釜还有哪些别名？
- 单层玻璃反应釜又称 单层玻璃反应器、玻璃反应釜。
- 单层玻璃反应釜有哪些供应商和生产厂家？
- 掌上化工当前收录 1 条单层玻璃反应釜供应报价，来自 1 家供应商，可按地区、纯度、级别筛选对比。
- 单层玻璃反应釜的供应商主要分布在哪些地区？
- 单层玻璃反应釜的供应商主要分布在 上海市（1 条） 等地。
- 单层玻璃反应釜有哪些级别可选？
- 平台上单层玻璃反应釜的供应级别包括 工业级。
- 单层玻璃反应釜的报价单位是什么？
- 单层玻璃反应釜的报价单位主要有 千克。
- 哪里可以查到单层玻璃反应釜的价格？
- 掌上化工单层玻璃反应釜产品页汇总了各供应商的最新报价与规格，地址：/chemicals/dan-ceng-bo-li-fan-ying-fu/。部分供应商价格为电议，可通过页面上的询价功能直接获取。
