HDPE钢带增强缠绕波纹管 (CAS No.None)
- 中文别名
- 钢带增强聚乙烯螺旋波纹管；金属增强缠绕结构壁管
- 英文名称
- HDPE Steel Belt Reinforced Spiral Corrugated Pipe
- 所属类别
- 塑料橡胶
- 物化性质
- 以高密度聚乙烯（HDPE）为基体，内外层与表面涂敷粘接树脂的钢带复合缠绕成型的结构壁管。管壁由三层构成：内层为连续实壁PE管，中间层为V型环状波状钢带增强体，外层为聚乙烯复合层。钢材的弹性模量约为190000 MPa，是聚乙烯的近200倍，兼具高刚度、高强度与塑料的耐腐蚀、耐磨损和柔韧性。环刚度可达SN8~SN16，耐酸碱及恶劣环境。
- 技术参数
- 环刚度等级可达到SN8、SN12.5和SN16，甚至更高。 钢带采用V型环状波状结构，钢的弹性模量约190000 MPa。 聚乙烯（PE）占复合管整体重量的约2/3。 与相同直径和环刚度的塑料管相比，可节省近一半材料用量。 钢带完全被内外聚乙烯层包覆，具有可靠的耐腐蚀和耐磨损性能。
English description（英文原文，共 1683 字符）
Product Name:HDPE Steel Belt Reinforced Spiral Corrugated Pipe
English Name:HDPE Steel Belt Reinforced Spiral Corrugated Pipe
Aliases:Steel Belt Reinforced PE Spiral Corrugated Pipe, Metal Reinforced Wound Structure Wall Pipe
Physical Properties:A structural wall pipe made of high-density polyethylene (HDPE) as the matrix, with inner and outer layers composited with a steel belt coated with adhesive resin. The wall structure consists of three layers: a continuous solid-wall PE inner pipe, a V-shaped annular corrugated steel belt reinforcement in the middle, and a polyethylene outer layer. The elastic modulus of steel is approximately 190000 MPa, nearly 200 times that of polyethylene, combining high stiffness and strength with the corrosion resistance, abrasion resistance, and flexibility of plastic. The ring stiffness reaches SN8~SN16 with good resistance to acids, alkalis, and harsh environments.
Uses:Suitable for various drainage and sewage systems in municipal, industrial, agricultural, and transportation projects, especially for buried pipelines and gravity flow conveyance in corrosive soil environments.
Technical Specifications:
Ring stiffness grades can reach SN8, SN12.5, and SN16, or even higher.
The steel belt adopts a V-shaped annular corrugated structure with an elastic modulus of about 190000 MPa.
Polyethylene (PE) accounts for approximately 2/3 of the total weight of the composite pipe.
Compared with plastic pipes of the same diameter and ring stiffness, it can save nearly half of the material consumption.
The steel belt is completely covered by inner and outer polyethylene layers, ensuring reliable corrosion and abrasion resistance.
English Name:HDPE Steel Belt Reinforced Spiral Corrugated Pipe
Aliases:Steel Belt Reinforced PE Spiral Corrugated Pipe, Metal Reinforced Wound Structure Wall Pipe
Physical Properties:A structural wall pipe made of high-density polyethylene (HDPE) as the matrix, with inner and outer layers composited with a steel belt coated with adhesive resin. The wall structure consists of three layers: a continuous solid-wall PE inner pipe, a V-shaped annular corrugated steel belt reinforcement in the middle, and a polyethylene outer layer. The elastic modulus of steel is approximately 190000 MPa, nearly 200 times that of polyethylene, combining high stiffness and strength with the corrosion resistance, abrasion resistance, and flexibility of plastic. The ring stiffness reaches SN8~SN16 with good resistance to acids, alkalis, and harsh environments.
Uses:Suitable for various drainage and sewage systems in municipal, industrial, agricultural, and transportation projects, especially for buried pipelines and gravity flow conveyance in corrosive soil environments.
Technical Specifications:
Ring stiffness grades can reach SN8, SN12.5, and SN16, or even higher.
The steel belt adopts a V-shaped annular corrugated structure with an elastic modulus of about 190000 MPa.
Polyethylene (PE) accounts for approximately 2/3 of the total weight of the composite pipe.
Compared with plastic pipes of the same diameter and ring stiffness, it can save nearly half of the material consumption.
The steel belt is completely covered by inner and outer polyethylene layers, ensuring reliable corrosion and abrasion resistance.
共 1 家生产厂家、批发商，
1 条供应报价
供应报价
常见问题
- HDPE钢带增强缠绕波纹管的 CAS 号是多少？
- HDPE钢带增强缠绕波纹管的 CAS 号是 None。
- HDPE钢带增强缠绕波纹管的英文名称是什么？
- HDPE钢带增强缠绕波纹管的英文名称为 HDPE Steel Belt Reinforced Spiral Corrugated Pipe。
- HDPE钢带增强缠绕波纹管还有哪些别名？
- HDPE钢带增强缠绕波纹管又称 钢带增强聚乙烯螺旋波纹管、金属增强缠绕结构壁管。
- HDPE钢带增强缠绕波纹管有哪些供应商和生产厂家？
- 掌上化工当前收录 1 条HDPE钢带增强缠绕波纹管供应报价，来自 1 家供应商，可按地区、纯度、级别筛选对比。
- HDPE钢带增强缠绕波纹管的供应商主要分布在哪些地区？
- HDPE钢带增强缠绕波纹管的供应商主要分布在 上海市（1 条） 等地。
- HDPE钢带增强缠绕波纹管有哪些级别可选？
- 平台上HDPE钢带增强缠绕波纹管的供应级别包括 工业级。
- HDPE钢带增强缠绕波纹管的报价单位是什么？
- HDPE钢带增强缠绕波纹管的报价单位主要有 千克。
- 哪里可以查到HDPE钢带增强缠绕波纹管的价格？
- 掌上化工HDPE钢带增强缠绕波纹管产品页汇总了各供应商的最新报价与规格，地址：/chemicals/hdpe-gang-dai-zeng-qiang-chan-rao-bo-wen-guan/。部分供应商价格为电议，可通过页面上的询价功能直接获取。
