聚苯醚PPO SE1GFN2工程塑料 (CAS No.None)
- 中文别名
- 聚苯醚；聚亚苯基醚；PPO；PPO SE1GFN2；玻纤增强聚苯醚
- 英文名称
- Polyphenylene Oxide (PPO) SE1GFN2 Engineering Plastic
- 分子式
- (C8H8O)n
- 所属类别
- 塑料橡胶
- 物化性质
- 聚苯醚（PPO）SE1GFN2是一款以聚苯醚为基体、添加20%玻纤增强的工程塑料。该材料密度为1.23 g/cm³，吸水率低（24小时仅0.06%），尺寸稳定性优异，模具收缩率仅为0.2-0.5%。玻璃化转变温度约210°C，线膨胀系数为3.6×10⁻⁵ 1/°C。材料本身具有优良的耐热性和阻燃性（UL 94 V-1，1.5mm），介电常数为2.98（60Hz），损耗因数0.0016（60Hz），电绝缘性能优异。同时其耐化学腐蚀性和耐水解性良好，适用于高温高湿环境。
English description（英文原文，共 1786 字符）
Product Name:Polyphenylene Oxide (PPO) SE1GFN2 Engineering Plastic
English Name:Polyphenylene Oxide (PPO) SE1GFN2 Engineering Plastic
CAS No.:25134-01-4
Aliases:Polyphenylene Oxide, Poly(p-phenylene oxide), PPO, PPO SE1GFN2, Glass Fiber Reinforced PPO
Molecular Formula:(C8H8O)n
Physical Properties:PPO SE1GFN2 is an engineering plastic based on polyphenylene oxide reinforced with 20% glass fiber. This material has a density of 1.23 g/cm³, ultra-low water absorption (only 0.06% in 24 hours), and excellent dimensional stability with a mold shrinkage of only 0.2-0.5%. The glass transition temperature is approximately 210°C, and the coefficient of linear thermal expansion is 3.6×10⁻⁵ 1/°C. The material exhibits excellent heat resistance and flame retardancy (UL 94 V-1 at 1.5mm), with a dielectric constant of 2.98 (60Hz) and dissipation factor of 0.0016 (60Hz), providing outstanding electrical insulation. It also demonstrates good chemical resistance and hydrolysis resistance, suitable for high-temperature and high-humidity environments.
Uses:Primarily used in electronic and electrical components such as connectors, coil bobbins, relays, and switch housings. Also applied in automotive parts and mechanical structural components, benefiting from its excellent dimensional stability and heat resistance, commonly found in precision instruments and insulating parts under high-temperature operating conditions.
Technical Specifications:
Tensile strength: 107 MPa (ASTM D-638, 3.2mm)
Flexural strength: 152 MPa (ASTM D-790, 6.4mm); Flexural modulus: 5719 MPa
Notched impact strength: 107 J/m (23°C, ASTM D-256); 96 J/m (-40°C)
Heat deflection temperature: 132°C (1.8MPa, ASTM D-648); 137°C (0.45MPa)
Flame rating: UL 94 V-1 (1.5mm); Dielectric constant: 2.98 (60Hz)
English Name:Polyphenylene Oxide (PPO) SE1GFN2 Engineering Plastic
CAS No.:25134-01-4
Aliases:Polyphenylene Oxide, Poly(p-phenylene oxide), PPO, PPO SE1GFN2, Glass Fiber Reinforced PPO
Molecular Formula:(C8H8O)n
Physical Properties:PPO SE1GFN2 is an engineering plastic based on polyphenylene oxide reinforced with 20% glass fiber. This material has a density of 1.23 g/cm³, ultra-low water absorption (only 0.06% in 24 hours), and excellent dimensional stability with a mold shrinkage of only 0.2-0.5%. The glass transition temperature is approximately 210°C, and the coefficient of linear thermal expansion is 3.6×10⁻⁵ 1/°C. The material exhibits excellent heat resistance and flame retardancy (UL 94 V-1 at 1.5mm), with a dielectric constant of 2.98 (60Hz) and dissipation factor of 0.0016 (60Hz), providing outstanding electrical insulation. It also demonstrates good chemical resistance and hydrolysis resistance, suitable for high-temperature and high-humidity environments.
Uses:Primarily used in electronic and electrical components such as connectors, coil bobbins, relays, and switch housings. Also applied in automotive parts and mechanical structural components, benefiting from its excellent dimensional stability and heat resistance, commonly found in precision instruments and insulating parts under high-temperature operating conditions.
Technical Specifications:
Tensile strength: 107 MPa (ASTM D-638, 3.2mm)
Flexural strength: 152 MPa (ASTM D-790, 6.4mm); Flexural modulus: 5719 MPa
Notched impact strength: 107 J/m (23°C, ASTM D-256); 96 J/m (-40°C)
Heat deflection temperature: 132°C (1.8MPa, ASTM D-648); 137°C (0.45MPa)
Flame rating: UL 94 V-1 (1.5mm); Dielectric constant: 2.98 (60Hz)
