聚对苯二甲酸丁二醇酯 (CAS No.None)
- 中文别名
- PBT；聚对苯二甲酸四亚甲基酯；聚(对苯二甲酸丁二醇酯)
- 英文名称
- Polybutylene terephthalate (PBT)
- 分子式
- (C12H12O4)n
- 所属类别
- 塑料橡胶
- 物化性质
- 聚对苯二甲酸丁二醇酯（PBT）为线性饱和聚酯，由对苯二甲酸与1,4-丁二醇缩聚而成。密度1.41 g/cm³，吸湿率（50%RH平衡）0.17%，吸水饱和0.42%；DSC熔点225℃，热变形温度在0.45MPa/1.80MPa/8.00MPa下分别为220℃/195℃/83℃，维卡软化温度（10N/50N）为221℃/205℃；热导率0.26 W/(m·K)，极限氧指数19%。电性能优异，表面电阻1×10^15Ω，相对介电常数100Hz下4.1、1MHz下3.5，电气强度27kV/mm（1mm厚）。
- 密度
- 1.41 g/cm³（ISO 1183）
English description（英文原文，共 1570 字符）
Product Name:Polybutylene terephthalate (PBT)
English Name:Polybutylene terephthalate (PBT)
CAS No.:26062-94-2
Aliases:PBT, Poly(butylene terephthalate), Poly(tetramethylene terephthalate)
Molecular Formula:(C12H12O4)n
Physical Properties:Polybutylene terephthalate (PBT) is a linear saturated polyester produced by polycondensation of terephthalic acid and 1,4-butanediol. Density is 1.41 g/cm³, moisture absorption (equilibrium 50% RH) 0.17%, saturation water absorption 0.42%; melting point (DSC) 225℃, heat deflection temperatures are 220℃/195℃/83℃ at 0.45 MPa/1.80 MPa/8.00 MPa, Vicat softening temperatures 221℃/205℃ (10 N/50 N); thermal conductivity 0.26 W/(m·K), limited oxygen index 19%. Excellent electrical properties: surface resistance 1×10^15 Ω, relative permittivity 4.1 (100 Hz) and 3.5 (1 MHz), electric strength 27 kV/mm (1 mm thickness).
Uses:Glass-fiber reinforced PBT offers excellent mechanical properties, heat resistance, electrical insulation and dimensional stability. It is widely used in electronic and electrical components (connectors, relays, switches, coil bobbins), automotive parts (sensor housings, lamp components, ignition parts) and mechanical parts. The 15% glass-fiber reinforced grade provides improved stiffness, creep resistance and dimensional accuracy compared with unreinforced PBT.
Technical Specifications:
Glass fiber content: 15%
Density: 1.41 g/cm³ (ISO 1183)
Tensile stress at break: 100 MPa (ISO 527-1/-2)
Tensile modulus: 6000 MPa (ISO 527-1/-2)
Heat deflection temperature (1.80 MPa): 195℃ (ISO 75-1/-2)
English Name:Polybutylene terephthalate (PBT)
CAS No.:26062-94-2
Aliases:PBT, Poly(butylene terephthalate), Poly(tetramethylene terephthalate)
Molecular Formula:(C12H12O4)n
Physical Properties:Polybutylene terephthalate (PBT) is a linear saturated polyester produced by polycondensation of terephthalic acid and 1,4-butanediol. Density is 1.41 g/cm³, moisture absorption (equilibrium 50% RH) 0.17%, saturation water absorption 0.42%; melting point (DSC) 225℃, heat deflection temperatures are 220℃/195℃/83℃ at 0.45 MPa/1.80 MPa/8.00 MPa, Vicat softening temperatures 221℃/205℃ (10 N/50 N); thermal conductivity 0.26 W/(m·K), limited oxygen index 19%. Excellent electrical properties: surface resistance 1×10^15 Ω, relative permittivity 4.1 (100 Hz) and 3.5 (1 MHz), electric strength 27 kV/mm (1 mm thickness).
Uses:Glass-fiber reinforced PBT offers excellent mechanical properties, heat resistance, electrical insulation and dimensional stability. It is widely used in electronic and electrical components (connectors, relays, switches, coil bobbins), automotive parts (sensor housings, lamp components, ignition parts) and mechanical parts. The 15% glass-fiber reinforced grade provides improved stiffness, creep resistance and dimensional accuracy compared with unreinforced PBT.
Technical Specifications:
Glass fiber content: 15%
Density: 1.41 g/cm³ (ISO 1183)
Tensile stress at break: 100 MPa (ISO 527-1/-2)
Tensile modulus: 6000 MPa (ISO 527-1/-2)
Heat deflection temperature (1.80 MPa): 195℃ (ISO 75-1/-2)
