LCP 5115L (CAS No.None)
- 物化性质
- LCP 5115L为热致液晶聚合物注塑级原料，熔融温度高，熔体粘度低，流动性好，近似于烯烃塑料；具有极小的线膨胀系数，尺寸稳定性好，吸水率低，耐化学药品性优良，固化速度快，成型周期短。
- 技术参数
- 熔融温度范围为300~425℃，料筒/喷嘴成型温度约为300~390℃。 模具温度建议设定为70~110℃，可调范围为30~150℃。 注射压力一般为15~45MPa，短时上限约为100MPa。 成型收缩率为0.1~0.6%，压缩比为2.5~4。 典型成型周期为10~30秒；含玻纤或碳纤增强牌号应适当降低螺杆转速，基准约100rpm。
English description（英文原文，共 1414 字符）
Product Name:LCP 5115L Liquid Crystal Polymer
English Name:LCP 5115L Liquid Crystal Polymer
CAS No.:No fixed CAS number (polymer blend)
Aliases:Liquid Crystal Polymer, LCP Resin, Thermotropic Liquid Crystal Polymer, LCP 5115L
Physical Properties:LCP 5115L is a thermotropic liquid crystal polymer injection molding grade with a high melting temperature, low melt viscosity, and excellent flowability similar to olefin plastics. It has a very low linear expansion coefficient, good dimensional stability, low water absorption, excellent chemical resistance, and fast solidification, resulting in a short molding cycle.
Uses:It is mainly used for electrical and electronic components such as connectors, relays, coil bobbins, switches, and sensors. It is also suitable for SMT components and precision injection-molded parts requiring high heat resistance, high dimensional stability, and thin-wall molding.
Technical Specifications:
Melting temperature range is 300–425°C; barrel/nozzle molding temperature is approximately 300–390°C.
Mold temperature should be set at 70–110°C, with an adjustable range of 30–150°C.
Injection pressure is generally 15–45 MPa, with a short-term upper limit of about 100 MPa.
Mold shrinkage is 0.1–0.6%; compression ratio is 2.5–4.
Typical molding cycle is 10–30 seconds; for glass/carbon fiber reinforced grades, reduce the screw speed from the baseline of about 100 rpm.
English Name:LCP 5115L Liquid Crystal Polymer
CAS No.:No fixed CAS number (polymer blend)
Aliases:Liquid Crystal Polymer, LCP Resin, Thermotropic Liquid Crystal Polymer, LCP 5115L
Physical Properties:LCP 5115L is a thermotropic liquid crystal polymer injection molding grade with a high melting temperature, low melt viscosity, and excellent flowability similar to olefin plastics. It has a very low linear expansion coefficient, good dimensional stability, low water absorption, excellent chemical resistance, and fast solidification, resulting in a short molding cycle.
Uses:It is mainly used for electrical and electronic components such as connectors, relays, coil bobbins, switches, and sensors. It is also suitable for SMT components and precision injection-molded parts requiring high heat resistance, high dimensional stability, and thin-wall molding.
Technical Specifications:
Melting temperature range is 300–425°C; barrel/nozzle molding temperature is approximately 300–390°C.
Mold temperature should be set at 70–110°C, with an adjustable range of 30–150°C.
Injection pressure is generally 15–45 MPa, with a short-term upper limit of about 100 MPa.
Mold shrinkage is 0.1–0.6%; compression ratio is 2.5–4.
Typical molding cycle is 10–30 seconds; for glass/carbon fiber reinforced grades, reduce the screw speed from the baseline of about 100 rpm.
