LCP/6130L BK010 (CAS No.None)
- 物化性质
- 密度1.62 g/cm³，熔融温度335°C，热变形温度（1.8 MPa，未退火）265°C，线形热膨胀系数（流动方向）3.0E-6 cm/cm/°C，横向7.0E-5 cm/cm/°C，表面电阻率和体积电阻率均大于1.0E+16，介电强度36 kV/mm，阻燃等级UL 94 V-0。
- 密度
- 1.62 g/cm³（ISO 1183）；熔融温度：335°C（ISO 11357-3）
English description（英文原文，共 1372 字符）
Product Name:LCP/6130L BK010
English Name:LCP/6130L BK010
Aliases:Liquid Crystal Polymer
Physical Properties:Density 1.62 g/cm³, melting temperature 335°C, heat deflection temperature (1.8 MPa, unannealed) 265°C, linear thermal expansion coefficient 3.0E-6 cm/cm/°C (flow direction) and 7.0E-5 cm/cm/°C (transverse direction), surface resistivity and volume resistivity both >1.0E+16, dielectric strength 36 kV/mm, flammability rating UL 94 V-0.
Uses:Suitable for electrical/electronic, aerospace, automotive and communication equipment fields, especially for manufacturing high-precision, heat-resistant electronic components and structural parts. It offers excellent mechanical strength, dimensional stability and flame retardancy.
Technical Specifications:
Density: 1.62 g/cm³ (ISO 1183); melting temperature: 335°C (ISO 11357-3)
Tensile modulus: 13000 MPa; tensile stress at break: 130 MPa; tensile strain at break: 1.8% (ISO 527-2)
Flexural modulus (23°C): 12000 MPa (ISO 178); Charpy notched impact strength (23°C): 25 kJ/m², unnotched: 35 kJ/m² (ISO 179)
Heat deflection temperature (1.8 MPa, unannealed): 265°C (ISO 75-2/A); linear thermal expansion coefficient: 3.0E-6 (flow), 7.0E-5 cm/cm/°C (transverse) (ISO 11359-2)
Surface resistivity/volume resistivity: >1.0E+16; dielectric strength: 36 kV/mm; flammability rating: UL 94 V-0 (0.38 mm and 1.50 mm)
English Name:LCP/6130L BK010
Aliases:Liquid Crystal Polymer
Physical Properties:Density 1.62 g/cm³, melting temperature 335°C, heat deflection temperature (1.8 MPa, unannealed) 265°C, linear thermal expansion coefficient 3.0E-6 cm/cm/°C (flow direction) and 7.0E-5 cm/cm/°C (transverse direction), surface resistivity and volume resistivity both >1.0E+16, dielectric strength 36 kV/mm, flammability rating UL 94 V-0.
Uses:Suitable for electrical/electronic, aerospace, automotive and communication equipment fields, especially for manufacturing high-precision, heat-resistant electronic components and structural parts. It offers excellent mechanical strength, dimensional stability and flame retardancy.
Technical Specifications:
Density: 1.62 g/cm³ (ISO 1183); melting temperature: 335°C (ISO 11357-3)
Tensile modulus: 13000 MPa; tensile stress at break: 130 MPa; tensile strain at break: 1.8% (ISO 527-2)
Flexural modulus (23°C): 12000 MPa (ISO 178); Charpy notched impact strength (23°C): 25 kJ/m², unnotched: 35 kJ/m² (ISO 179)
Heat deflection temperature (1.8 MPa, unannealed): 265°C (ISO 75-2/A); linear thermal expansion coefficient: 3.0E-6 (flow), 7.0E-5 cm/cm/°C (transverse) (ISO 11359-2)
Surface resistivity/volume resistivity: >1.0E+16; dielectric strength: 36 kV/mm; flammability rating: UL 94 V-0 (0.38 mm and 1.50 mm)
共 1 家生产厂家、批发商，
1 条供应报价
供应报价
常见问题
- LCP/6130L BK010的 CAS 号是多少？
- LCP/6130L BK010的 CAS 号是 None。
- LCP/6130L BK010的英文名称是什么？
- LCP/6130L BK010的英文名称为 LCP/6130L BK010。
- LCP/6130L BK010还有哪些别名？
- LCP/6130L BK010又称 液晶聚合物、液晶高分子。
- LCP/6130L BK010有哪些供应商和生产厂家？
- 掌上化工当前收录 1 条LCP/6130L BK010供应报价，来自 1 家供应商，可按地区、纯度、级别筛选对比。
- LCP/6130L BK010的供应商主要分布在哪些地区？
- LCP/6130L BK010的供应商主要分布在 上海市（1 条） 等地。
- LCP/6130L BK010有哪些级别可选？
- 平台上LCP/6130L BK010的供应级别包括 工业级。
- LCP/6130L BK010的报价单位是什么？
- LCP/6130L BK010的报价单位主要有 千克。
- 哪里可以查到LCP/6130L BK010的价格？
- 掌上化工LCP/6130L BK010产品页汇总了各供应商的最新报价与规格，地址：/chemicals/lcp-6130l-bk010/。部分供应商价格为电议，可通过页面上的询价功能直接获取。
