LCP5130L塑胶原料 (CAS No.None)
- 中文别名
- 液晶高分子；LCP树脂；液晶聚合物树脂
- 英文名称
- Liquid Crystal Polymer (LCP) 5130L
- 分子式
- (C7H4O2)x(C11H6O2)y
- 所属类别
- 塑料橡胶
- 物化性质
- 液晶聚合物（LCP）是一种芳香族主链热致液晶聚酯，具有自增强性。密度约1.60 g/cm³，熔点约330-360°C，热变形温度≥260°C，连续使用温度约220-240°C。耐化学药品性、耐水解性和阻燃性优异，UL94阻燃等级达V-0；吸水率低，尺寸稳定性好，介电强度高，流动性良好，适合薄壁精密成型。
- 密度
- 约1.62 g/cm³。
English description（英文原文，共 1299 字符）
Product Name:Liquid Crystal Polymer (LCP) 5130L
English Name:Liquid Crystal Polymer (LCP) 5130L
CAS No.:81843-52-1
Aliases:LCP resin, Liquid crystalline polymer, LCP plastic raw material
Molecular Formula:(C7H4O2)x(C11H6O2)y
Physical Properties:LCP is an aromatic main-chain thermotropic liquid crystalline polyester with self-reinforcing properties. It has a density of about 1.60 g/cm³, melting point of approximately 330-360°C, heat deflection temperature ≥260°C, and continuous service temperature of about 220-240°C. It offers excellent chemical resistance, hydrolysis resistance and flame retardancy (UL94 V-0), low water absorption, good dimensional stability, high dielectric strength, and good flowability for thin-wall precision molding.
Uses:Used in automotive parts such as engine control units, lamp sockets and sensor housings; in electronic and electrical components such as connectors, relays, switches and coil bobbins; and in power tool accessories such as motor insulation parts and brush holders. Suitable for thin-wall, precision and high-temperature injection molding.
Technical Specifications:
Glass fiber content: 30%.
Density: approx. 1.62 g/cm³.
Tensile strength: ≥150 MPa.
Heat deflection temperature (1.82 MPa): ≥260°C.
Flammability rating: UL94 V-0 (0.8 mm).
English Name:Liquid Crystal Polymer (LCP) 5130L
CAS No.:81843-52-1
Aliases:LCP resin, Liquid crystalline polymer, LCP plastic raw material
Molecular Formula:(C7H4O2)x(C11H6O2)y
Physical Properties:LCP is an aromatic main-chain thermotropic liquid crystalline polyester with self-reinforcing properties. It has a density of about 1.60 g/cm³, melting point of approximately 330-360°C, heat deflection temperature ≥260°C, and continuous service temperature of about 220-240°C. It offers excellent chemical resistance, hydrolysis resistance and flame retardancy (UL94 V-0), low water absorption, good dimensional stability, high dielectric strength, and good flowability for thin-wall precision molding.
Uses:Used in automotive parts such as engine control units, lamp sockets and sensor housings; in electronic and electrical components such as connectors, relays, switches and coil bobbins; and in power tool accessories such as motor insulation parts and brush holders. Suitable for thin-wall, precision and high-temperature injection molding.
Technical Specifications:
Glass fiber content: 30%.
Density: approx. 1.62 g/cm³.
Tensile strength: ≥150 MPa.
Heat deflection temperature (1.82 MPa): ≥260°C.
Flammability rating: UL94 V-0 (0.8 mm).
