PA66 FR50 (CAS No.None)
- 物化性质
- 密度1.60 g/cm³（ISO 1183）；收缩率（垂直/流动）0.80%/0.30%（ISO 294-4）；吸水率（23°C，50%RH，2mm）0.70%；拉伸模量10600 MPa，断裂应力170 MPa，断裂应变2.5%；弯曲模量9450 MPa；简支梁缺口冲击强度（23°C）11 kJ/m²；热变形温度（0.45MPa）256°C，（1.8MPa）246°C；玻璃化转变温度80°C；熔融温度261°C；线膨胀系数（流动/横向）1.9E-5/1.0E-4 cm/cm/°C；体积电阻率>1.0E+15 ohm·cm；介电强度38 kV/mm；损耗因数0.018（100Hz/1MHz）；CTI 285V；阻燃等级V-0（0.35mm/1.5mm）。
- 密度
- 1.60 g/cm³（ISO 1183）
English description（英文原文，共 1494 字符）
Product Name:Polyamide 66 FR50
English Name:Polyamide 66 FR50
CAS No.:32131-17-2
Aliases:Nylon 66, PA66, Poly(hexamethylene adipamide)
Molecular Formula:(C12H22N2O4)n
Physical Properties:Density 1.60 g/cm³ (ISO 1183); water absorption 0.70% (23°C, 50% RH, 2 mm); tensile modulus 10600 MPa, tensile stress at break 170 MPa, tensile strain at break 2.5%; flexural modulus 9450 MPa; Charpy notched impact strength 11 kJ/m² (23°C); heat deflection temperature 256°C (0.45 MPa) and 246°C (1.8 MPa); glass transition temperature 80°C; melting temperature 261°C; linear thermal expansion coefficient 1.9E-5/1.0E-4 cm/cm/°C (flow/transverse); volume resistivity >1.0E+15 ohm·cm; dielectric strength 38 kV/mm; dissipation factor 0.018 (100Hz/1MHz); CTI 285V; flammability rating V-0 (0.35 mm/1.5 mm).
Uses:PA66 FR50 is a flame-retardant grade nylon 66 suitable for general-purpose and film molding. It offers excellent mechanical strength, heat resistance, and electrical insulation, and is commonly used in electronic components, automotive structural parts, industrial connectors, and flame-retardant films. Its V-0 flammability rating meets the safety requirements for thin-wall parts.
Technical Specifications:
Density: 1.60 g/cm³ (ISO 1183)
Tensile modulus: 10600 MPa, tensile stress at break: 170 MPa (ISO 527-2)
Heat deflection temperature (1.8 MPa): 246°C (ISO 75-2/A)
Volume resistivity: >1.0E+15 ohm·cm (IEC 60093)
Flammability rating: V-0 (0.35 mm and 1.5 mm, IEC 60695-11-10,-20)
English Name:Polyamide 66 FR50
CAS No.:32131-17-2
Aliases:Nylon 66, PA66, Poly(hexamethylene adipamide)
Molecular Formula:(C12H22N2O4)n
Physical Properties:Density 1.60 g/cm³ (ISO 1183); water absorption 0.70% (23°C, 50% RH, 2 mm); tensile modulus 10600 MPa, tensile stress at break 170 MPa, tensile strain at break 2.5%; flexural modulus 9450 MPa; Charpy notched impact strength 11 kJ/m² (23°C); heat deflection temperature 256°C (0.45 MPa) and 246°C (1.8 MPa); glass transition temperature 80°C; melting temperature 261°C; linear thermal expansion coefficient 1.9E-5/1.0E-4 cm/cm/°C (flow/transverse); volume resistivity >1.0E+15 ohm·cm; dielectric strength 38 kV/mm; dissipation factor 0.018 (100Hz/1MHz); CTI 285V; flammability rating V-0 (0.35 mm/1.5 mm).
Uses:PA66 FR50 is a flame-retardant grade nylon 66 suitable for general-purpose and film molding. It offers excellent mechanical strength, heat resistance, and electrical insulation, and is commonly used in electronic components, automotive structural parts, industrial connectors, and flame-retardant films. Its V-0 flammability rating meets the safety requirements for thin-wall parts.
Technical Specifications:
Density: 1.60 g/cm³ (ISO 1183)
Tensile modulus: 10600 MPa, tensile stress at break: 170 MPa (ISO 527-2)
Heat deflection temperature (1.8 MPa): 246°C (ISO 75-2/A)
Volume resistivity: >1.0E+15 ohm·cm (IEC 60093)
Flammability rating: V-0 (0.35 mm and 1.5 mm, IEC 60695-11-10,-20)
