PBT GP-2306F 30玻纤增强 (CAS No.None)
- 中文别名
- 聚对苯二甲酸丁二醇酯；PBT树脂；聚对苯二甲酸丁二酯
- 英文名称
- PBT GP-2306F 30% Glass Fiber Reinforced
- 分子式
- (C12H12O4)n
- 所属类别
- 塑料橡胶
- 物化性质
- 30%玻纤增强PBT，外观为自然色颗粒；比重1.62 g/cm³，成型收缩率0.3-1.0%，吸水率0.07%；熔融指数10 g/10min(250℃/2.16kg)；热变形温度210℃(1.80MPa)，熔融温度223℃；体积电阻率1.0×10^17 Ω·cm，绝缘强度28 kV/mm，耐电弧性120s；阻燃等级UL94 V-0（0.71mm, 1.5mm, 3.0mm）。
- 技术参数
- 比重1.62 g/cm³，成型收缩率0.3-1.0%，吸水率0.07%。 拉伸强度132 MPa，断裂伸长率2%，弯曲强度191 MPa，弯曲模量8829 MPa，悬臂梁缺口冲击强度70 J/m。 热变形温度210℃（1.80 MPa，未退火），熔融温度223℃。 体积电阻率1.0×10^17 Ω·cm，绝缘强度28 kV/mm。 阻燃等级UL94 V-0（0.71mm/1.5mm/3.0mm），建议干燥温度110-120℃，干燥时间4-6h。
English description（英文原文，共 1690 字符）
Product Name:PBT GP-2306F 30% Glass Fiber Reinforced
English Name:PBT GP-2306F 30% Glass Fiber Reinforced
CAS No.:26062-94-2
Aliases:Polybutylene terephthalate, Polytetramethylene terephthalate
Molecular Formula:(C12H12O4)n
Physical Properties:30% glass fiber reinforced PBT, natural color pellets; specific gravity 1.62 g/cm³, mold shrinkage 0.3-1.0%, water absorption 0.07%; melt flow index 10 g/10min (250°C/2.16kg); heat deflection temperature 210°C (1.80MPa), melting temperature 223°C; volume resistivity 1.0×10^17 Ω·cm, dielectric strength 28 kV/mm, arc resistance 120s; flammability rating UL94 V-0 (0.71mm, 1.5mm, 3.0mm).
Uses:PBT GP-2306F is widely used in electronic and electrical appliances such as connectors, switches, household appliances, and small power tool housings; in the automotive industry for exterior parts (corner grilles, engine radiator vent covers), interior parts (inner mirror brackets, wiper supports, control system valves), and automotive electrical parts (ignition coil casings, electrical connectors); also used in mechanical equipment for gears, cams, camera parts, and other components requiring heat resistance and flame retardancy.
Technical Specifications:
Specific gravity 1.62 g/cm³, mold shrinkage 0.3-1.0%, water absorption 0.07%.
Tensile strength 132 MPa, elongation at break 2%, flexural strength 191 MPa, flexural modulus 8829 MPa, notched Izod impact strength 70 J/m.
Heat deflection temperature 210°C (1.80 MPa, unannealed), melting temperature 223°C.
Volume resistivity 1.0×10^17 Ω·cm, dielectric strength 28 kV/mm.
Flammability rating UL94 V-0 (0.71mm/1.5mm/3.0mm), recommended drying temperature 110-120°C, drying time 4-6h.
English Name:PBT GP-2306F 30% Glass Fiber Reinforced
CAS No.:26062-94-2
Aliases:Polybutylene terephthalate, Polytetramethylene terephthalate
Molecular Formula:(C12H12O4)n
Physical Properties:30% glass fiber reinforced PBT, natural color pellets; specific gravity 1.62 g/cm³, mold shrinkage 0.3-1.0%, water absorption 0.07%; melt flow index 10 g/10min (250°C/2.16kg); heat deflection temperature 210°C (1.80MPa), melting temperature 223°C; volume resistivity 1.0×10^17 Ω·cm, dielectric strength 28 kV/mm, arc resistance 120s; flammability rating UL94 V-0 (0.71mm, 1.5mm, 3.0mm).
Uses:PBT GP-2306F is widely used in electronic and electrical appliances such as connectors, switches, household appliances, and small power tool housings; in the automotive industry for exterior parts (corner grilles, engine radiator vent covers), interior parts (inner mirror brackets, wiper supports, control system valves), and automotive electrical parts (ignition coil casings, electrical connectors); also used in mechanical equipment for gears, cams, camera parts, and other components requiring heat resistance and flame retardancy.
Technical Specifications:
Specific gravity 1.62 g/cm³, mold shrinkage 0.3-1.0%, water absorption 0.07%.
Tensile strength 132 MPa, elongation at break 2%, flexural strength 191 MPa, flexural modulus 8829 MPa, notched Izod impact strength 70 J/m.
Heat deflection temperature 210°C (1.80 MPa, unannealed), melting temperature 223°C.
Volume resistivity 1.0×10^17 Ω·cm, dielectric strength 28 kV/mm.
Flammability rating UL94 V-0 (0.71mm/1.5mm/3.0mm), recommended drying temperature 110-120°C, drying time 4-6h.
