注塑机接料皮带输送机，机械手配套输送线 (CAS No.None)
- 中文别名
- 机械手配套输送线；槽型皮带输送机；爬坡皮带输送机；转弯皮带输送机
- 英文名称
- Injection Molding Machine Receiving Belt Conveyor
- 所属类别
- 塑料橡胶
- 物化性质
- 输送平稳，物料与输送带间无相对运动，可避免损坏物料；结构简单，便于维护；能耗低，使用成本低。输送带材质有橡胶、帆布、PVC、PU等，可满足耐油、耐腐蚀、防静电、食品专用等要求。
- 技术参数
- 标准输送带宽度为200、300、400、500、600、700、800、900、1000、1200mm等，也可按客户需求定制特殊规格。 转弯皮带机标准转弯内半径为R600、R900、R1200mm等，也可按客户需求定制。 机械手旁小型流水线动力采用180W马达，配1:50减速箱，变频调速，速度1-5米/分钟。 机身采用40×80铝型材（2.0mm），机脚采用30×60铝型材，皮带采用5mm绿色PVC防滑皮带，宽400mm，无缝接口。 皮带下承托采用1mm镀锌托板，机脚配脚轮，整线尺寸总长50米×宽900毫米×高850毫米。
English description（英文原文，共 1475 字符）
Product Name:Injection Molding Machine Receiving Belt Conveyor
English Name:Injection Molding Machine Receiving Belt Conveyor
Aliases:Robot Auxiliary Conveyor Line, Trough Belt Conveyor, Inclined Belt Conveyor, Curved Belt Conveyor
Physical Properties:Smooth conveying with no relative movement between materials and belt, preventing damage to conveyed items; simple structure, easy maintenance; low energy consumption and operating cost. Belt materials include rubber, canvas, PVC, PU, etc., meeting special requirements such as oil resistance, corrosion resistance, antistatic, and food-grade applications.
Uses:Suitable for injection molding machine receiving and robot auxiliary conveyor lines, used for smooth conveying of bagged or light single-piece goods, as well as general industrial material handling.
Technical Specifications:
Standard belt widths: 200, 300, 400, 500, 600, 700, 800, 900, 1000, 1200mm; special sizes customizable.
Standard inner turning radius of curved belt conveyor: R600, R900, R1200mm; special sizes available on request.
Small conveyor line beside robot: powered by 180W motor with 1:50 gearbox, variable frequency speed control, speed 1-5 m/min.
Frame made of 40×80 aluminum profile (2.0mm), legs of 30×60 aluminum profile; belt is 5mm green PVC anti-slip belt, 400mm wide with seamless joint.
Belt supported by 1mm galvanized support plate, legs equipped with casters; overall dimensions: 50m length × 900mm width × 850mm height.
English Name:Injection Molding Machine Receiving Belt Conveyor
Aliases:Robot Auxiliary Conveyor Line, Trough Belt Conveyor, Inclined Belt Conveyor, Curved Belt Conveyor
Physical Properties:Smooth conveying with no relative movement between materials and belt, preventing damage to conveyed items; simple structure, easy maintenance; low energy consumption and operating cost. Belt materials include rubber, canvas, PVC, PU, etc., meeting special requirements such as oil resistance, corrosion resistance, antistatic, and food-grade applications.
Uses:Suitable for injection molding machine receiving and robot auxiliary conveyor lines, used for smooth conveying of bagged or light single-piece goods, as well as general industrial material handling.
Technical Specifications:
Standard belt widths: 200, 300, 400, 500, 600, 700, 800, 900, 1000, 1200mm; special sizes customizable.
Standard inner turning radius of curved belt conveyor: R600, R900, R1200mm; special sizes available on request.
Small conveyor line beside robot: powered by 180W motor with 1:50 gearbox, variable frequency speed control, speed 1-5 m/min.
Frame made of 40×80 aluminum profile (2.0mm), legs of 30×60 aluminum profile; belt is 5mm green PVC anti-slip belt, 400mm wide with seamless joint.
Belt supported by 1mm galvanized support plate, legs equipped with casters; overall dimensions: 50m length × 900mm width × 850mm height.
